2 Liter Vacuum Filter Funnel System, Reusable PP with PEEK or Stainless Steel Fluid Path
- Part Number:
- PLS-8000-1020
- Lead Time:
- 3-5 days
- Shipping:
- FREE SHIPPING on most orders over $50*
- Quantity:
- each
- Size:
- 1 liter / 32 ounce
- Material:
- polypropylene
- Style:
- filtration
- Closure Style:
- screw thread
- Country of Origin:
- Made in the USA
Bulk discount rates
Automatically save when you buy in bulk.
| Buy 6 - 11 | and get 10% off |
| Buy 12 or above | and get 15% off |
Description
This 2 Liter Vacuum Filter Funnel system is made of durable polypropylene, PEEK and stainless steel. It is easy to set up and use, and is virtually indestructible. Complete 2 Liter Vacuum Filter Funnel system includes: vacuum filter manifold (w/ O-ring, GL-45 Cap, 53B Cap, stainless steel vacuum port) , filter retainer ring, 2 Liter capacity plastic funnel, stainless steel filter support, and adapter kit. Use with CG-8088-1L or CG-8088-2L . (Due to the wide range of available options, media bottle and filter paper are not included.)
Choose your own 47mm filter paper based on your filtration needs.
The CP Lab Safety Vacuum Filter System offers several improvements over conventional designs. Engineered for durability and ease of use, this unit features an O-ring seal which makes it easy to seat on a standard GL-45 cap closure reagent bottle. The vacuum port has stainless steel 1/4"-28 threads to last longer than other units and interface with standard fittings. The unique retainer ring prevents the filter membrane from twisting and becoming damaged. We hope you will agree that this simple, innovative design is an improvement over anything else on the market.
Polypropylene base manifold and funnel, PTFE retainer ring, stainless steel threads in the vacuum port, and a stainless steel or Peek membrane filter support.
|
Seal |
Silicone rubber O-ring, capable of withstanding autoclaving. Designed primarily for aqueous solutions. Other O-ring materials are available for filtering more aggressive liquids. If you have special filtration needs, contact us regarding a filter design that can meet your requirements. |
|
Capacity |
Available with either 1 or 2 liter funnel. |
|
Set-up |
Extremely easy to set up and use. First, lay the stainless steel membrane filter support into the recessed area on top of the base manifold. Place the filter membrane on top and install the retainer ring on top of that. Lift the white threaded cap to engage the threads of the funnel and screw together snugly. Next, insert the base manifold into the neck of a GL-45 receiving bottle and tighten the cap snugly. Finally, choose the proper adapter combination to connect up to your vacuum source. |
|
Clean-up |
Extremely easy. The entire unit may be submerged in water or other solutions for cleaning. Or the entire unit may be autoclaved. |
Stainless Steel or PEEK fluid path:
- Choose from a standard fluid path or a non-metallic fluid path depending on your application.
- Stainless steel threads in the vacuum port ensure that this connection is vacuum tight. No standard fitting will strip these threads.
- The stainless steel or PEEK membrane filter support and the retainer ring ensure that filter media remains flat and undamaged.
For the price, you will not find a more durable and easy-to-use product. Consider these benefits and compare our unique features with other units on the market:
Features & Benefits:
- Accepts 47mm filter paper. (Ex: Whatman PTFE 47mm 0.2 micron filter media)
- No need for intermediate containers for your filtrate. Solutions are filtered directly into sterile reservoirs.
- The unit fits snugly onto standard reservoir bottles with GL-45 cap closures.
- Rugged polypropylene construction means the filtration apparatus is nearly indestructible.
- Stainless steel threads in the vacuum port ensure they will not be stripped ruin the unit.
- The retainer ring keeps the filter membrane flat and undamaged.
- Use with a 1 or 2 liter media bottle. Larger size bottles are not recommended for this system.
Adapters & Fittings
The unit is shipped complete with an inline filter adapter cap, base manifold with vacuum port, stainless steel membrane filter support, retainer ring, complete adapter kit and a product data sheet (instructions and information.) If you need extra adapters and fittings you can order additional adapter kits via quotation.
Each Adapter Kit contains:
- 1 ea. 1/4"-28 to Female Luer Adapter
- 1 ea. 1/4"-28 Male Luer
- 1 ea. Male Luer to 1/4" Barb
- 1 ea. Male Luer to 3/16" Barb
- 1 ea. Male Luer to 1/8" Barb
- 1 ea. Male Luer Integral Lock Plug Ring
- 1 ea. 1/4" to 3/16" Connector
- 1 ea. 3/8" to 1/4" Connector.
The 1/4"-28 to female Luer adapter interfaces to a variety of different barb fittings included in each Adapter Kit. These barb adapters allow you to interface the unit with almost any vacuum source.
